CT-3716

6-channel RTD-PT100 temperature acquisition module.

Compatible with 2-wire or 3-wire PT100 sensors.

15-bit ADC resolution; measurement range: -240°C to 870°C.

Accuracy: ±0.5°C.

Magnetic isolation between field inputs and internal bus (2.5kVrms).

LED indicators for each input channel.

Conversion time: 400ms for all channels.

DIN-rail mount, IP20 rated, 115×14×75 mm, 65g.
